Tomei Ti Racing Titanium Muffler for (R)PS13/S14/S15



Ti RACING, the latest and pinnacle exhaust series from TOMEI.

An enlarged 80.5 mm main pipe that is the largest in the market.
Yet, the meticulously refined piping layout achieves maximum ground clearance while maintaining an authentic, uncompromised performance and appearance.
Significant weight reduction, distinctive looks, the iconic racing sound and tone precisely tuned to stir your soul.
Ti RACING is TOMEI’s ultimate answer for those who demand the best of the best from titanium, the ultimate material for exhaust systems.



PRODUCT INFO

APPLICATION		P/N	NOTES
SR20DET	(R)PS13	441015	*FOR OFF ROAD USE ONLY.
	S14	441016
	S15	441017



FEATURE / SPEC

Ti RACING Titanium Exhaust series has been designed to improve total performance while reducing the sound as much as possible to meet the sound regulation at the tracks, while EXPREME Ti series has been designed just to unleash engine’s true potential and improve the total performance.



ORIGINAL TITANIUM MATERIAL To ensure and maintain reasonable price, supreme quality and stable supply, this product is made from TOMEI original titanium material which is refined from raw material and made into performance parts all under quality controlled environment.		APPEARANCE MATTERS The iconic rainbow hues of burnt titanium, paired with a laser engraved TOMEI logo, define our all-new end tip, redesigned to perfectly complement each model’s bumper fascia and express its authentic performance.		PRECISION WELDS Titanium is known as a difficult material to weld. Its strength, long-life and beautiful appearance all prove the true quality.
MAIN MUFFLER Large muffler shell with the straight flow structure eliminates problem of sound issues at the track without reducing performance.Stamped TOMEI logo and gradation titanium color on the mirror finished resonator.		HIGH QUALITY GLASS WOOL Filled with even more glass wool comparing to existing EXPREME Ti series to reduce and tune the sound.High quality long filament glass wool is very durable and prevents aging deteriorations caused by continues high heat and high pressure.		SOUND REDUCER/SILENCER The kit comes with end silencer baffles that can be attached as needed to comply with various environmental restrictions.



KIT CONTENTS

・MAIN PIPE A (1) ・MAIN PIPE B (1) ・SILENCER ASSY (1) ・FLANGE NUT M10 (2) ・GASKET (1) ・CLAMP BAND (2) ・SPRING (4)

・SILENCER BAND (1) ・SILENCER BAND RUBBER (1) ・FLANGE NUT M8 (1) ・FLANGE BOLT M8 (1) ・BUTTON BOLT M6 (1) ・SOUND REDUCER (1) ・ALLEN KEY (1)



SPEC

Designed for results, not too thick or thin. For best overall power gains, weight reductions and value for money.

	Ti RACING	(R)PS13 STD	S14 STD	86 early model STD
MATERIAL	TITANIUM	STEEL	STAINLESS	STAINLESS
MAIN PIPE DIAMETER	Φ80.5	Φ54.0	–	Φ17-63
MAIN SILENCER DIAMETER	Φ152	–	–	–
SUB SILENCER DIAMETER	Φ120	–	–	–
PIPE THICKNESS	1.0mm	1.5mm	–	1.5mm
EXIT DIAMETER	Φ115/STRAIGHR CUT	Φ38.1×2	–	Φ48.6×2
FLANGE THICKNESS	8.0mm	8.0mm	8.0mm	8.0mm
FLANGE INNER DIA.	Φ80.5	–	–	–
EXHAUST TEST LEVELS	IDLING:81.0db 4500RPM:103.2db	–	IDLING:61.8db 4500RPM:82.1db	–
WEIGHT	6.3kg	14.5kg	16.0kg	16.0kg



LAYOUT

Maximum ground clearance, no compromise.
Through a meticulously refined piping layout, the new design gains 2 mm of additional clearance at the differential and 18 mm at the main resonator compared to the previous model.

Comparison with Previous Models
① Next to Differential: -2 mm / ② Front of Muffler: -19 mm / ③ Rear of Muffler: -18 mm



STYLE

S14



S15
